Home » Bearings » SKF Imp Self Aligning Ball Bearing , 2307 EKTN9/C3
SKF

SKF Imp Self Aligning Ball Bearing , 2307 EKTN9/C3

Only 1 left
Rs. 5,270.00
Sale Rs. 6,431.00 Rs. 5,270.00
+ 18% GST

BEST OFFERS FOR YOU!

Enjoy 2% off on your first purchase! Copy the coupon code and apply it at checkout.


Bore Diameter 35 mm
Outside diameter 80 mm
Width 31 mm
Basic dynamic load rating 39.7 kN
Basic static load rating 11.2 kN
Limiting speed 12 000 r/min
Reference speed 16 000 r/min
Bore type  Tapered 1:12
Product net weight 0.638 kg
Lubricant
 None



PRODUCT DESCRIPTION

Self-aligning ball bearings, with a tapered bore, have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. They are insensitive to angular misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection. The tapered bore facilitates ease of mounting via adapter sleeves or withdrawal sleeves. Ease of mounting via adapter sleeves or withdrawal sleeves Accommodate static and dynamic misalignment Excellent high-speed performance Excellent light load performance Low friction.
