Mahr Analog Calipers, MarCal 30 N, Art. no. 4127301
Regular price
Rs. 0.00
+ 18% GST
BEST OFFERS FOR YOU!
Enjoy 2% off on your first purchase! Copy the coupon code and apply it at checkout.
Product Description
Art. no. 4127301
Depth Gage MarCal 30 N
Measuring range: 0 - 200 mm
Readings mm: 0.05 mm
Package contains: case
- Vernier and scale have a satin chrome finish for glare free reading
- Locking screw below
- Hardened measuring pin
- Measuring surfaces made of steel
- Interchangeable beams
Technical Specifications
|
MarCal 30 N | Art. no. 4127301 |
|
|---|---|
|
Measuring range |
0 - 200 mm |
|
Readings mm |
0.05 mm |
|
Error limit (mm) |
0.05 mm |
|
Standard |
DIN 862 |
|
Dimensions |
a 1.5 mm | b 100 mm | c 285 mm | d 8 mm | g 3.5 mm | |
Variety of applications for our products
Interchangeable measuring rail with 2 different measuring surfaces
- Straight rod: for conventional depth measurements
- Stylus: for measurements in narrow grooves, small bores or uneven surfaces
